JTS RU-850LTB, Trådløs Beltesender

This innovative bodypack transmitter is designed with both REMOSET U and full function setting at itself. The settings include Frequency, Group/Channel, Sensitivity, RF Power, and Auto Power Off. All data will be transferred to this transmitter by pushing of the REMOSET U button at receiver’s front panel. Auto Power Off feature can be set OFF or ON with selection of 1, 10 and 30 minutes without audio input. This will save batterylife and avoid over discharge.

Besides REMOSET U a user can carry out setting at transmitter side. To cope with music instruments a pad of -20 dB is designed.

Recharging circuit and connecter are already built in case users want to upgrade the system.

Technical spesifications

* 1440 Selectable channels. (depending on region)
RU-850LTB
UHF PLL Body-Pack Transmitter
Frequency Preparation:
PLL Synthesized Control
Carrier Frequency Range: 470~960MHz
Frequency Setting:REMOSET U (Receive)
RF Outpus: Low / High
Stability: <±10KHz@Fc
Frequency Deviation: ±48KHz
Spurious Emissions: <-50dBc
Function: Mute, Auto Power Off, Sensitivity
Adjust, Low Battery
Display: LCD+LED
Input Connector: 4P Mini XLR
Controls: Power, Mute, Group, Channel,
Frequency, Gain Adjust, Auto Power Off,
Key Lock
Battery: UM3, AA x2

(*depending on region)
