PROLIGHTS PIXIESPOT, Moving head
LED Spot 1x60W RGBW/FC Sort
PIXIESPOT it's the first Prolights spot moving head delivering a full spectrum chromatic synthesis, equipped with a 60W RGBW/FC LED light source to perform limitless bright, intense and saturated colors, as well as proper whites. PIXIESPOT can be also controlled wireless through the optional USB Wi-Fi receiver in combination with Wifibox and the smartphone App SmartColor.
Features:
60W RGBW/FC Osram ostar LED source
Color mixing featuring rich saturated and pastel colors and white reproduction as well
Effect section equipped with 3f circular prism
Gobo wheel: 7 rotating Gobos
USB IN for control through SmartColor App through WIFIUSB
LIGHT SOURCE
- Source: 60W RGBW Osram LEDs
- Luminous Flux: 1069lm
- Lux: 1682lux @3m Full
- Source Life Expectancy: >50.000 h
OPTICS
- Beam Angle: 18°
- Lens Type: HQ glass lens optics
- Focus: Motorised
COLOR SYSTEM
- Color Mixing: RGBW/FC
- CTC: Linear CTO correction 2700~6000K
- Color Wheel: Virtual color wheel with presets
DYNAMIC EFFECTS
- Rotating Gobos: 7 Rotating gobos+Open, Interchangeable
- Gobo Size: gobo Ø 16,9 mm - img Ø 14 mm - 2 mm
- Circular Prism: 3f with bi-directional rotation
- Auto Mode: Built-in programs with execution speed adjustment
- Sound Mode: Music activation through internal microphone, sensitivity contr.
BODY
- Pan Angle: 540°
- Tilt Angle: 270°
- Pan/Tilt Resolution: bit 8/16 bit
- Body: Aluminium structure with hi-resistance polycarbonate cover
- Body Color: Black, White finishing available
CONTROL
- Protocols: DMX512
- DMX Channels: 15/18/23ch
- Display: Black OLED high resolution display
- Firmware Upgrade: Yes, via USB-DMX interface (UPBOX1) not included
- Master/Slave: for synchronized operation of more units linked in a chain
ELECTRONICS
- Dimmer: Linear 0~100% electronic dimmer
- Dimmer Curves: Different dimming curves available
- Strobe/Shutter: 1/28 Hz, electronic
- Operating Temperature: -10° ~ +45°
- Flicker: Flicker free operation
ELECTRICAL
- Power Supply: 100-240V – 50/60Hz
- Power Consumption (at 230V): 118W
- Power Consumption (at 120V): 120,3W
- Output (at 230V): 17 units on a single power line
- Output (at 120V): 9
PHYSICAL
- Cooling: Forced air with low noise fan
- Suspension And Fixing: Any position with “quick-lock” omega brackets
- USB: USB port for USB Wi-Fi receiver (optional)
- Signal Connection: 3p in/out
- Power Connection: IEC 10A in/out
- IP: 20
- Dimensions (WxHxD): 253x352x192mm
- Weight: 7kg
